Giới thiệu Thiết Bị Bảo Vệ Mạch Tự Điều Chỉnh 220v Svp-918
Features: New SVP-918 automatic adjustable over-voltage protection limit current protector with manual key single-phase 230V.
Functions: 1. Over voltage protection 2. Undervoltage protection 3. Over current protection 4. Automatic recovery 5. Adjustable recovery delay time 6. Voltage display (voltage measurement) 7. Current display (current measurement)
Specifications: 1. Model: SVP-918 2. Power supply: 230VAC 50 / 60Hz 3. Maximum load power: 1-40A adjustable (default: 40A) 1 ~ 63A adjustable (default: 63A) 4. Overvoltage protection value range: 230V-300-off (default: 280V) 5. Under voltage protection value range: 210V ~ 140V ~ off (default: 160V) 6. Over current regulation range: 1-40A (default: 40A) 1 ~ 63A (default: 63A) Overcurrent recovery current value: 1A less than the overcurrent protection value 7. Recovery delay time: 1s ~ 300s (default: 30s) 8. Motor life: > 50000 times 9. Installation: 35mm DIN rail 10.Material: abs + electronic components 11.Size: 8.5x6.5x3.7cm
Notes: 1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you! 2. Please allow 1-3cm measuring deviation due to manual measurement.
