yal SSOP8 TSSOP8 Programmer Adapter Socket TSSOP TO DIP Converter Chip Test Outlet

Giới thiệu yal SSOP8 TSSOP8 Programmer Adapter Socket TSSOP TO DIP Converter Chip Test Outlet

100% brand new and high quality
Features:
Made of high quality material, solid, durable, high strength and good performance, long service life.
It adopts double contact technology, the contact is more stable (see the schematic below).
The shrapnel is made of imported beryllium copper material with low impedance and good elasticity;
The gold plating layer is thickened, the contact thickening plating, ultra-low contact resistance and high reliability;
Adapter chip body width is 4.4mm; easy to operate, very convenient.

Specification:
Material: PPS, Metal
Insulation Resistance: 1000mΩ Min, At DC 500V
Withstand Voltage : 700AC/1Minute
Contact Resistance: <25mΩ
PIN Root Elasticity: 55g / PIN (Normal)
Mechanical Life : 100000Times
Working Temperature: -65 - 155℃/149 - 311℉
Operating Force: Less than 0.9kg Max
Size: app.3.6 x 2.4cm/1.42 x 0.94in
Color: Green and Black
Quantity: 1 Pc

Note:
No retail package.
Please allow 0-1cm error due to manual measurement. pls make sure you do not mind before you bid.
Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!

Package includes:
1 x Programmer Adapter
