Thiết Bị Kiểm Tra Cáp Mạng Đa Năng Rj45 Rj11 Ethernet Lan

Giới thiệu Thiết Bị Kiểm Tra Cáp Mạng Đa Năng Rj45 Rj11 Ethernet Lan

_______♤Welcome Iuxishop Store♤___________

✔Ready Stock
✔COD
✔Quality Checked
✔Whole Items: Good Quality/Ready Stock/Original/Wholesale Price
✔Shipping Time: 5-14 usually 8 days from China

★Surprises for you★
☛Free Gifts:Follow Shop
❤“Like” 5 Items: Priority Shipping
⚠️( Sent us follow shop screenshot and remark on your order "Free Gift", if not will miss)

✌(Tip:We will be based on your guests in your country to send the corresponding adapter plug)

【After-sale】: If there are any problem, please contact us firstly, we will try our best to solve it.

__________________❀Product Information❀__________________


Features:
1. Designed for test the wire circuit state of network cable, telephone cable, such as open, short, cross, etc
2. High quality network cable tester suitable for testing both RJ45 Ethernet cables and RJ11 cables.
3. This model adopt automatic scan model, which can rapidly get a test result.
4. The tester has a detachable section making it perfect for testing cable runs in different locations.
5. With this network cable tester, you can judge wrong connection, short circuit and open circuit.
6. Compact and light weight network cable tester, useful for home and outside use.


Specification:
Condition: 100% Brand New
Weight: Approx. 115g / 4.1oz
Size: Approx. 10.5 * 9.8 * 2.8cm / 4.1 * 3.9 * 1.1in

Instructions:
1. Testing double twisted cables 1,2,3,4,5,6,7,8 and G corresponding ,and tell users which exact line is on wrong circuit.
2. Switch ON is the normal test speed, "S" is the rapid test speed, and OFF is Turn off the Tester.
3.Turn on the tester, insert the line connector into main tester and remote control. Then the indication lights(1 to G) will flash
Main tester:                1-2-3-4-5-6-7-8-G
Remote control tester: 1-2-3-4-5-6-7-8-G（RJ45）
                                     1-2-3-4-5-6------   （RJ12）
                                     1-2-3-4----------    （RJ11)
If the connection is not normal, it will be displayed as follows:
1.When there is a network cable such as NO. 3 cable is open circuit, the main tester and remote test end NO.3 lights is not on.
2.When several cables are open circuit, several cables are not on. When less than two cables are connected, the lights are not on.
3.When the two ends of network cables are in disorder, for example, cable 2 and 4 are in disorder, it is shown as follows:
Main tester unchanged: 1-2-3-4-5-6-7-8-G
Remote tester: 1-4-3-2-5-6-7-8-G
4. When there are two wires short circuits, the main tester does not light up, while the remote test end shows that both of the two line lights of short circuit are dim. If there are more than 3 (including 3) short circuits, all the lights of several wires Numbers of short circuit will not light up.


Package List:
1 * Network Cable Tester

Hình ảnh sản phẩm

Giá VMPX
