Động Cơ Bước 2 Pha 0.9 Độ 17hs4401s Cho Máy In 3d Cnc Kèm Dây Cáp 1m

Giới thiệu Động Cơ Bước 2 Pha 0.9 Độ 17hs4401s Cho Máy In 3d Cnc Kèm Dây Cáp 1m

Features:
0.9°step angle, holding torque ≥280mN.m, 4.3V rated voltage, 1.3A rated current.
0.9° pulse resolution is higher than 1.8°, the processing technology is more complicated, and the accuracy is higher.
Lower noise, high torque, stable property and high accuracy.
Comes with 1 * 42 stepper motor and 1m wire.
Motor size: 42 * 42 * 38mm (1.7 * 1.7 * 1.5in).


Specifications:
Color: Black
Phase: 2
Step Angle: 0.9°±5%
Rated Voltage: 4.3V
Rated Current: 1.3A
Resistance(20°): 2.2*(1±15%)Ω
Inductance: 5.7*(1±20%)mH
Holding Torque: ≥280mN.m
Rotor Inertia: 57g.cm3
Insulation Class: B
Insulation Resistance: ≥200MΩ(DC 500v)
Ambient Temperature: 24°C~+80°C
Relative Humidity: 90%MAX
Life Time: 5000 hours
Item Weight: 263g / 9.3oz
Package Size: 10.2 * 6.8 * 4.8cm / 4.0 * 2.7 * 1.9in
Package Weight: 295g / 10.4oz
Packing List:
1 * Stepper Motor
1 * Wire(1m)
