DC Động Cơ Bánh Răng Dioo 30-600rpm Dc Với Trục Nối Dài Chuyên Dụng N20

Giới thiệu DC Động Cơ Bánh Răng Dioo 30-600rpm Dc Với Trục Nối Dài Chuyên Dụng N20

--------------------------------------------- *Welcome Dioo Store* ----------------------------------------------
❀We insist on giving you the best products at the lowest price❀
✔Ready to sent ✔High quality ✔Best price
☛Free Gifts:Follow Shop
☞PS: If you want a free gift, please send me the screenshot that you follow my shop and leave a message on your order.
--------------------------------------------------- * Product * ---------------------------------------------------


Features:
This DC motor features large moment of force, low speed, and low noise.
The motor is made of metal gear, wear-resisting, avoid tooth breaking, so with long serving life.
This electronic gear motor is good replacement for old or worn electronic deceleration motor, useful and practical.
Suitable for lifts, landing gear, mechanical ,electronic toys and many other devices.
This motor is adopted of pure copper wire coil, with low heat and low loss.

Specification:
Model: GA12N20-M4100
Rated power: 2W
Optional type: 6V 30RPM, 6V 60RPM, 6V 100RPM, 6V 150RPM, 6V 200RPM, 6V 300RPM, 6V 400RPM, 6V 500RPM, 12V 300RPM, 12V 400RPM, 12V 600RPM
3C rated voltage range:
Tread type: M4
Output shaft length: 100mm / 3.9inch
Length: Approx. 125mm / 4.9inch
Weight: Approx. 19g / 0.7oz
Voltage
Gear Ratio
No Load
Load Torsion
Stall
Speed
Current
Speed
Current
Torsion
Current
Torsion
6V
1:298
30RPM
≤40mA
23RPM
≤40mA
440gf.cm
≤1.1A
3.3kgf.cm
6V
1:298
60RPM
≤40mA
50RPM
≤40mA
560gf.cm
≤1.1A
3.6kgf.cm
6V
1:100
100RPM
≤50mA
83RPM
≤45mA
320gf.cm
≤1.1A
2.25kgf.cm
6V
1:100
150RPM
≤50mA
130RPM
≤45mA
260gf.cm
≤1.1A
2.50kgf.cm
6V
1:50
200RPM
≤50mA
180RPM
≤45mA
160gf.cm
≤1.1A
1.60kgf.cm
6V
1:50
300RPM
≤50mA
240RPM
≤50mA
190gf.cm
≤1.1A
2.0kgf.cm
6V
1:50
400RPM
≤50mA
350RPM
≤70mA
210gf.cm
≤1.1A
2.2kgf.cm
6V
1:50
500RPM
≤70mA
440RPM
≤100mA
220gf.cm
≤1.1A
2.4kgf.cm
12V
1:100
300RPM
≤50mA
240RPM
≤60mA
550gf.cm
≤1.1A
3.6kgf.cm
12V
1:50
400RPM
≤50mA
310RPM
≤45mA
280gf.cm
≤1.1A
2.4kgf.cm
12V
1:50
600RPM
≤50mA
500RPM
≤50mA
310gf.cm
≤1.1A
3.0kgf.cm

Package List:
1 x Gear Motor

Note:
1. Please allow small size error due to manual measurement. Thanks for your understanding.
2. Only a gear motor, no other stuff included.
