DC 3-6V High Voltage Pulse Generator 400KV Arc Coil Module

Giới thiệu DC 3-6V High Voltage Pulse Generator 400KV Arc Coil Module

The module can output high voltage pulse current, small size and high efficiency.
This module is the finished module of transformer for small scientific production.
The input voltage is DC 3V-6V and will output DC high voltage.

Features:
The module can output
high voltage pulse current, small size and high efficiency.
This module is the finished module of transformer for small scientific production.
The input voltage is DC 3V-6V and will output DC high voltage.
It can be used as high voltage power source in high school science
experiment, electronic instrument, anion generator.
The peripheral
circuit is simple, simply connect the switch and battery, and the discharge
intensity is great.

Specification:
Input Voltage: 3V-6V DC
Input Current: 2A-5A
High Voltage Type: Pulse current
Output Voltage: About 400KV
Arc Discharge Distance: 10mm-20mm
Output Cable Length: About 100mm / 3.9in
Input Wire Length: About 100mm / 3.9in
Power Source: One or two 3.7V li-ion batteries, such as 18650, phone battery(remove protection board, suggested capacity is above 2000mAh) or NiCd/Ni-MH battery pack, 4V or 6V lead-acid storage battery
Weight: 37g / 1.3oz (approx.)

Package list:
1 * High Voltage Generator
Wiring: Red wire is power source positive. Output are 2 high temperature high voltage resistant silicone cables.
Note: The product can not be use to ignite or light up a cigarette.

#HighVoltageGenerator #PulseCoilModule #HighVoltageArcModule #PulseGenerator #ArcCoil Module
