Dây Cáp Sạc Bamaxis Cabledeconn Sas 38pin Sff-8654 Sang Server Hdd

Giới thiệu Dây Cáp Sạc Bamaxis Cabledeconn Sas 38pin Sff-8654 Sang Server Hdd

__________________♤#Bamaxis ♤___________________
Welcome to my store ,We insist on the lowest price to sell the best quality items

✔Ready to sent✔Good quality✔Best price
★★Surprises for you★★
❤Follow shop/ “Like” Items: Priority Shipping & Free Gift
❤PS: If you want a free gift, please send me the screenshot that you follow my shop and leave a message on your order.

Features:
1. Smaller size connectors and cables save space on the equipment.
2. Provide four-channel signal transmission according to industry standards.
3. Data rate: 12 Gbps per channel SAS.
4. Compliant with SAS3.0, SlimSAS SFF-8654 specification.
5. Applications: Servers, data storage, workstations.

Specification:
Brand: Cabledeconn
Cable length: 1m / 3.28ft
Mechanical behavior:
Combining ability: up to 55.5N
Uncooperative force: up to 49N
Rated durability cycle: a minimum of 250 cycles
Electrical performance:
Voltage: 30VDC per touch
SlimSAS 4i plug: up to 80mohm. Initially, the pressure test was maximum 20mohm.
Dielectric withstand voltage: minimum 300 VDC for 100 ms
Insulation resistance: the minimum value between adjacent pins is 10MΩ
Signal integrity:
Paired connector impedance: 100 ± 10% ohms
Common mode impedance: in accordance with SAS3.0 specification
Insertion loss: in accordance with SAS3.0 specification
Maximum crosstalk: in accordance with SAS3.0 specification
Product environmental compliance:
RoHS2.0: Compliance with standards
China RoHS: Yes
REACH SVHC: Yes

Package List:
1 * Data Cable
