Bộ chuyển đổi PCI-E sang 2 thẻ nối + 1 khe cắm song song mở rộng PCI LPT chất lượng cao

Giới thiệu Bộ chuyển đổi PCI-E sang 2 thẻ nối + 1 khe cắm song song mở rộng PCI LPT chất lượng cao

___________________❀Alwaysonline❀___________________
Welcome to our store, we insist on the lowest price to sell the best quality items.
✔Ready Stock ✔Wholesale Price ✔Quality Checked

★Surprises for you★
☞Shop Voucher: Get More Discount
☞Follow Shop: Free Gifts
☞“Like” Items: Priority Shipping
( Sent us follow shop screenshot and remark on your order "Free Gift", if not will miss)

★★Attention Please★★
✌We will be based on your guests in your country to send the corresponding adapter plug.

_______________❀Product Information❀______________



Features:
1. It is easy to allow more serial and parallel devices to be connected to your computer.
2. Two 9-pin RS-232 DB9 external serial ports and one DB 25 external parallel LPT port.
3. Complies with PCI Express Specification Revision 1.1.
4. WCH382 master chip, stable and powerful.
5. PCI Express single lane (x1) bus bandwidth 2.5 Gbps.
6. Support for DOS, Windows 8 / 7 / Vista / XP / 2000 / Server 2003-2008 32/64 bit, Linux operating system.

Specifications:
Compliant with PCI-Express Specification Revision 1.1
PCI-Express Single-Lane (x1) bus bandwidth 2.5Gbps
Support for DOS, Windows 8 / 7 / Vista / XP / 2000 / Server 2003-2008 32/64-bit, Linux and other operating systems
Parallel interface (LPT)
I/O address: assigned by BIOS
IRQ: Assigned by BIOS
Support for SPP, PS2, EPP & ECP and mode
Serial interface (RS232)
Compliant with industry standard 16C450/16C550 UART
The chip has a built-in 256-byte FIFO and on-chip H/W, S/W flow control function.
The data transmission rate of each serial port can reach 250Kbps (customized data transmission can reach 1Mbps)
Baud rate: 230.4Kbps
Serial communication parameters Data bits: 5, 6, 7, 8
Stop position: 1, 2
Parity: None, Even, Odd, Space, Mark
Flow control: RTS/CTS, XON/XOFF
I/O address: assigned by BIOS
IRQ: Assigned by BIOS
Serial signal for RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND

Package List:
1 * riser card
1 * cover board
1 * serial cable
