Bo mạch chủ MSI H510M Pro-E CHÍNH HÃNG

Giới thiệu Bo mạch chủ MSI H510M Pro-E CHÍNH HÃNG

⛪⛪⛪ QUANGVYPC STORE - KHO HÀNG MỚI CHÍNH HÃNG MSI VIỆT NAM ⛪⛪⛪
📞📞📞 HOTLINE HỖ TRỢ 24/7 : 0973.007.002 📞📞📞
=======================================================================

***THÔNG TIN CƠ BẢN SẢN PHẨM :
BỘ XỬ LÝ :
Supports 10th Gen Intel® Core™ Processors, 11th Gen Intel® Core™ Processors, Pentium® Gold and Celeron®

CHIPSET :
Intel® H510 Chipset

BỘ NHỚ :
2x DDR4 memory slots, support up to 64GB1
Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel® CPU (by JEDEC & POR)
Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel® CPU (by JEDEC & POR)
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)

KHE MỞ RỘNG :
1x PCIe x16 slot (From CPU)
Support up to PCIe 4.0 for 11th Gen Intel® CPU
Support up to PCIe 3.0 for 10th Gen Intel® CPU
2x PCIe 3.0 x1 slots (From PCH)

ĐỒ HOẠ TÍCH HỢP :
1x VGA port, supports a maximum resolution of 2048x1536 60Hz, 1920x1200 60Hz
1x HDMI 1.4 port, supports a maximum resolution of 4K 30Hz

CỔNG USB :
Intel® H510 Chipset
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
6x USB 2.0 ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 2.0 connector)

ÂM THANH :
Realtek® ALC897 Codec
7.1-Channel High Definition Audio

CỔNG LAN :
1x Realtek® RTL8111 Gigabit LAN controller

KẾT NỐI BÊN TRONG :
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
4x SATA 6Gb/s connectors
1x USB 3.2 Gen 1 5Gbps connector (support additional 2 USB ports)
1x USB 2.0 connector (support additional 2 USB ports)
1x 4-pin CPU fan connector
1x 4-pin system fan connector
1x Front panel audio connector
2x System panel connectors
1x Serial port connector
1x Chassis Intrusion connector
1x Clear CMOS jumper
1x TPM module connector

KÍCH THƯỚC :
mATX Form Factor
9.3 x 7.5 in. (23.6 cm x 19.0 cm)

#mainboard #msi #h510
