Bảng Mạch Điều Khiển Skr E3 Dip V1.1 32bit Tft24 Cho Máy In 3d

Giới thiệu Bảng Mạch Điều Khiển Skr E3 Dip V1.1 32bit Tft24 Cho Máy In 3d

BIGTREETECH SKR E3 DIP V1.1 32Bit Control Board Motherboard with TFT24 TouchScreen Display Kits 3D Printer Parts for Ender-3
Features:
BIGTREETECH SKR E3 DIP V1.1, perfect upgrade of Ender 3 machine motherboard.
ARM Cortex-M3 series STM32F103RCT6 chip with 32-bit CPU 72MHz.
Support BIGTREETECH TFT24 TFT28 TFT35 color touchscreen and Ender 3D printer original LCD 12864 screen.
Support the function blocking rotation detection, shutdown after printing, etc.
Support A4988,DRV8825,LV8729,ST820,TMC2208,TMC2209,TMC2130,TMC5160 stepper motor drive.
Integration of TMC2130 and TMC5160 SPI Mode, DIAG Extended Port in the integration SPI Mode, easy to replace Endstop Function.

Specifications:
Microprocessor: ARM Cortex-M3 CPU
Power Voltage: 12/24V
Installation Size: Perfectly replaces the original Ender 3 motherboard
Support Driver: A4988,DRV8825,LV8729,ST820,TMC2208,TMC2209,TMC2130,TMC5160
DIAG Extended Port: Integrate
Display Screen: Support BIGTREETECH TFT24 TFT28 TFT35 color touchscreen and Ender 3D printer original LCD 12864 screen
Item Size: 10 * 7cm / 3.9 * 2.8in
Package Size: 20.0 * 12.5 * 8.0cm / 7.9 * 4.9 * 3.1in
Package Weight: 290g / 10.2oz
Packing List:
1 * Control Board
1 * USB Cable
4 * Heat Sink
5 * Jumper Cap
1 * TFT24 TouchScreen
3 * Wire

Hình ảnh sản phẩm
