Bộ 5 Bảng Mạch Phát Triển Wifi Wlan Cho Esp8266

Giới thiệu Bộ 5 Bảng Mạch Phát Triển Wifi Wlan Cho Esp8266

The controllers are easy to program by using the CP2102-USB interface without having to press the flash and reset buttons before each flash operation.
The development board has integrating GPIO, PWM, IIC, 1-Wire and ADC all in one board. Support smart link smart networking.
The fast and affordable technology for WiFi. Make your development the fastest way combined with firmware for NodeMcu.
ern, state-of-the-art LUA technology. It is an integrated unit with all available resources on board. It's very easy for Arduino projects or any development board with I / O pins.
ern Internet development tools can use the built-in API to instantly put your idea on the fast track.

Support wireless 802.11b/g/n standard
Support three working es of STA/AP/STA+AP
Built-in TCP/IP protocol stack, supports multiple TCP Client connections (5MAX)
D0~D8, SD1~SD3: used as GPIO, PWM, I2C, etc., port drive capability 15mA
AD0: 1 channel ADC
Power input: 4.5V~7V, support USB power supply
Working current: continuous transmission: approximately equal to 70mA (200mA MAX), standby Less than 200uA
Transmission rate: 110-460800bps
Support UART/GPIO data communication interface
Colour:black
Material:PC+metal

Package Contents:
5 x ESP8266 IoT Development BoardOnly the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
