2Pin K Head Braided Wire Earpiece Headphone for Kenwood Baofeng UV 5R Radio

Giới thiệu 2Pin K Head Braided Wire Earpiece Headphone for Kenwood Baofeng UV 5R Radio

Feature:
Nylon braided wire, super tensile, durable.
Silicone ear hook, soft and comfortable, wearing is not easy to fall off.
Widely used in police, army, bodyguards and other security personnel, in catering, hotels, clubs, outdoor sports and other aspects play an important role.

Specification:
Colour: Black
Line length: about 1.2m/3.9ft
Plug: 2 pins for KENWOOD

Microphone:
Ambient noise of mic: 36 dB (maximum)
Mic reference operating voltage: 3V DC
Mic current consumption: 0.5mA (maximum)
Voltage range of middlehead: 1~10V DC
Mic impedance: 2.2 ohms (maximum)
Mic sensitivity: 60 dB + 2 dB

Horn:
Horn Impedance: 150 +15% Ohm
Horn sensitivity: 130dB
Horn frequency range: 20-20KHz
Horn Effective Test Range Frequency: 30-5000Hz
Horn distortion: less than 5%
Horn rated power: 10 mW
Horn maximum power: 15mW
Horn Abnormal Sound: 0.5V (50Hz-5KHz) No Abnormal Sound

Applicable models (including but not limited to)
For for Kenwood KPG:
KPG27D,KPG29D,KPG48D,KPG49,KPG55D,KPG56D,KPG62D,KPG66D,
KPG69D,KPG70D,KPG74D,KPG75D,KPG77D,KPG82D,KPG87D
For Kenwood TH:
TH-D7,TH-D7A,TH-D7AG,TH-D7E,TH-F6,TH-F6A,TH-F7,TH-F7E,TH-G71,TH-G71A,TH-G71E,TH-K2,TH-K2A,TH-K2E,TH-K2ET,TH-21,TH-21AT,TH-21BT,TH-22,Th-22A,TH-22At,TH-22E,TH-25,TH-26,TH-27,TH-28,TH31AT,TH41AT,TH41BT,TH-42,TH-42A,TH-42AT,TH-42E,TH-45,TH-46,TH-47,TH-48,TH-55,TH-75,TH-77,TH-G71,TH-205,TH-215,TH-225,TH-235,TH-235A,TH-235E,TH-315,TH-415
For Kenwood TK:
TK-208/308,TK-220/320,TK-240/340,TK-240D/340D,TK-248/348,TK-250/350/353,TK-260/360,TK-260G/360G,TK-270/370,TK-270G/370G,TK-272G/372G/373G,TK-278G/378G/388GPro-Talk,TK-430/431,TK-2100/3100Pro-Talk,TK-2102/3102
Pro-Power,TK-2107/3107
Pro-Talk,TK2207,TK3207,TK-2160/3160
For BAOFENG:
Almost All: UV5R,UV8,UV8D,UVB5,UVB6,A52,UV5RA,UV5RC,UV5RD,UV5RE,UV5RE+,F8,F8+
BF480/490/320/V6/V7/V8/658/520/530/999/888/777/666s/777s/888s/F8+/A5/388A
For POFUNG:
UV-A52,UV-82,UV-8,UV-6,UV-5R,888s,5RA
For HYT:
TC286/386/2685/3865/6685/278/378/388/2100/2088
For PUXING:
PX-777,PX-888,PX-888K,PX-325,PX-358
For QUSHENG/for LINTON/for TYT etc
Almost all with a two pin plug, Former pin diameter of 3.5mm and 2.5mm in diameter after pin, double pin from 8 min within,11 mm center distance of 2 pin.

Note:
Please allow 1-3mm differs due to manual measurement.
Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.


Included:

1 X 2Pin K Head Braided Wire Earpiece
